HZS60 concrete mixing plant

　　HZS60 concrete mixing plant is a fully automatic concrete mixing plant equipment composed of batching device, aggregate conveying device, powder conveying device, water supply additive system, metering system, mixing system, electric control system and gas control system. HZS60 concrete mixing plant has the characteristics of reasonable structure, excellent performance, reliable operation, easy operation, accurate measurement, etc., suitable for roads, airports, ports, hydropower and other large projects and precast components, commercial concrete and other large quantities of concrete production, is widely used in various engineering construction.

　　1. Modular structure, quick installation and disassembly, convenient transportation. With a variety of layout forms, can adapt to the requirements of different sites.

　　2. The mixing machine adopts JS1000 type double horizontal shaft forced concrete mixer, which has good mixing quality and high productivity, and can complete good mixing of dry hard, semi-dry hard, plastic and various proportions of concrete in an ideal time.

　　3. All metering components and control components of the measuring unit are imported components, microcomputer control, fully ensure accurate measurement and stable performance.

　　4. All powdered materials, from feeding, batching, metering, feeding to mixing and discharging are carried out in a closed state. High-quality dust collector is used in the main mixing building, and the packaging of the main mixing building and the belt conveyor is closed, which reduces the pollution of dust and noise to the environment and has good environmental protection performance.

　　5. Each repair and maintenance part is provided with a platform or ladder, and the main machine is cleaned with a high-pressure pump cleaning device, which has good maintenance performance.

　6. The whole machine adopts dual computer control system, which can automatically ensure the continuous production control of the system without influence when the two machines are switched. Dynamic panel display, can clearly understand the operation of each part. Intuitive monitoring interface, can clearly and accurately observe the field workflow. Reports can be printed and managed.

　　7. Electronic control system components using imported components, the overall performance is stable, powerful. Abnormal working conditions and fault automatic detection, using text, sound, light, alarm prompts, convenient maintenance and elimination of faults.

project	Maximum productivity	Mixer model	Batcher model	Discharge height	Working cycle time	Weighing accuracy
HZS60	60m3/h	JS1000	PLD1600	3800（mm）	72（S）	aggregate 2%	cement 1%	water 1%	Additives 1%
