Features
The large-scale concrete pump HBT80B-16-110S is designed for high-rise buildings, bridges and other large-scale concrete projects,with high construction efficiency and large output. Optional with a wire or wireless remote control device to facilitate long-distance operation;proximity switch non-contact commutation to ensure reliable system commutation. The concrete transfer pump-HBT80B-13-90S adopts a three-circuit open hydraulic system.The main pump has a constant power control and pressure cut-off device, so that the main pump can obtain multi-level reliability protection.The centralized automatic lubrication system is adopted, and a pressure filter is provided at the outlet of the lubrication pumpto ensure reliable lubrication of the lubrication points.
Working Rrinciple:
The main pump has a constant power control and pressure cut-off device, so that the main pump can obtain multi-level reliability protection.The centralized automatic lubrication system is adopted, and a pressure filter is provided at the outlet of the lubrication pumpto ensure reliable lubrication of the lubrication points.
Product Advantages:
1. The power system adopts a well-known brand motor with anti-pumping function, which facilitates the timely removal of plugging faults and can be stopped in a short time.
2. Optimized hopper, better suction.
3. Automatically centralized lubrication system to ensure the most effective lubrication during operation.
4. The imported Korean Kawasaki main oil pump saves energy and has good performance.
Technical Data:
Theoretical concrete output | m3/h | 90/54 |
Theoretical pump pressure | MPa | 16/9 |
Aggregate size | mm | Pebble≤50 Lithotripsy≤40 |
power | KW | Diesel engine174 |
speed | r/min | 2300 |
Pump cylinder bore / stroke | mm | ￠140/1800 |
Concrete cylinder diameter / stroke | mm | ￠200/1800 |
High and low voltage switching | yes | |
Tank volume | L | 500 |
Fuel tank volume | m3 | 0.8 |
Hopper volume | mm | 1400 |
Theoretical transmission distance vertical / horizontal | m | 350/1600 |
Pipeline cleaning method | washing | |
Shape size (long x wide x high) | mm | 6200×2100×2260 |
Whole machine quality | kg | 6300 |
